DAMAR KCD Electric Winch — Single Phase
Price on Request
Selected configuration: KCD - 1 TON SINGLE PHASE
Product Details
- Model
- Single-hook: KCD-1 TON SINGLE PHASE / Double-hook: KCD -1 TON SINGLE PHASE
- Method of use
- Single-hook / Double-hook
- Rated voltage (V)
- 220/380
- Input power (W)
- 1800
- Capacity (kg)
- Single-hook: 500 / Double-hook: 1000
- Lifting speed (m/min)
- Single-hook: 16 / Double-hook: 8
About This Item
- A compact powered winch designed for workshops and sites using readily available single-phase power, bringing dependable mechanical advantage to repeated lifting and pulling tasks.
- The KCD drum-and-wire-rope format offers a direct, uncomplicated lifting arrangement that is easy to integrate into suitable frames and site setups.
- Its 1,800 W copper-wound motor and 2,800 rpm motor speed give this 1 Ton model a strong, purposeful drive system for repeated winching work.
- Electric operation helps reduce manual handling effort and supports more consistent work cycles than a hand-operated alternative.
- A generously sized steel rope drum, high-grade steel frame and heat-treated load components create a weighty, durable machine built to handle demanding service.
Product Description
The DAMAR single-phase KCD electric winch range provides wire-rope handling options where a single-phase model is required. The listed 1 ton and 1.5 ton models have different ratings in single-hook and double-hook use; the model name is not the load capacity in every arrangement. Review the selected configuration for capacity, lifting speed and power requirements, and confirm the available electrical supply before ordering. Include the intended application, model, hook arrangement, quantity and delivery location in your quotation enquiry. Not for lifting people.
Images are illustrative, and specifications may change. Please obtain written confirmation of all important specifications before ordering. Read the Product & Safety Disclaimer.
Specifications
KCD - 1 TON SINGLE PHASE
| Model | Method of use | Rated voltage (V) | Input power (W) | Capacity (kg) | Lifting speed (m/min) | Weight (kg) | Motor speed (rpm) |
|---|---|---|---|---|---|---|---|
| KCD-1 TON SINGLE PHASE | Single-hook | 220/380 | 1800 | 500 | 16 | 27 | 2800 |
| KCD -1 TON SINGLE PHASE | Double-hook | 220/380 | 1800 | 1000 | 8 | 27 | 2800 |
Supply & certificates
Manufacturer’s test certificates are supplied with all products. Government-approved test house certificates for wire rope slings and chain slings can be arranged at an additional charge. This requirement must be specified when placing the order; requests cannot be accommodated after the slings have been manufactured and dispatched.
We are wholesale distributors supplying across India. Spare parts are available for selected products. We do not provide repairs, servicing or technical assistance.
No warranty or guarantee is offered. This does not exclude rights that apply under applicable law.
